溫度空氣浴: 10 – 65°C +/- 0.2°C

低溫恒溫浴(選配件 沒包含):

-10 – 100°C +/- 0.2°C

顯示 設置溫度和測試溫度

電源 90-240 VAC 50/60 Hz

其他細節 ST-100 適用于 RM 300所有的同軸轉子。

尺寸 (WxLxH) 和 重量 電子控制盒:

257 x 267 x 200 mm

Stand: 197 x 280 x 485 mm

15 kg

轉子            參考      轉子規格  樣品量 粘度范圍

MK-DIN 145 112504  45 mm _ 3 - 900 000 mPa.s

MK-DIN 125 112503  25 mm _ 5 - 5 000 000 mPa.s

MK-DIN 114 112502  14 mm _ 15 - 30 000 000 mPa.s

MK-DIN 108 112501  8 mm _ 80 - 150 000 000 mPa.s

MB-DIN 145T

cup 112512  48.5 mm 100 ml _

MB-DIN 125T

cup 112511  27.5 mm 20 ml _

MB-DIN 114T

cup 112510  15 mm 5 ml _

MB-DIN 108T

cup 112509  8.5 mm 2 ml _

MK-MS0 112702  46.5 mm _

1 - 28 000 mPa.s

MS-0 cup 112701  50 mm 20 ml

MK-C 112525  13.6 mm _ 50 mPa.s - 50 000 000 mPa.s

MK-C2 112550  17.6 mm _ 20 mPa.s - 20 000 000 mPa.s

MK-C4 112552  19 mm _ 2 - 900 000 mPa.s

MB-C cup 112524  20 mm 20 ml

應用：

食品行業/化工行業/教學/化妝品/制藥/建筑業/涂料/墨水/汽車業

=====================================

Peltier ST-100 stand is made for measurement

with coaxial cylinders measuring systems of

RM 300. It is thermostated by Peltier effect,

that enables a quick thermal exchange in

warming or refreshing phase. It works either

with ambient air without cooling fluid

between 10 to 65°C, either related to an

external cooling bath (non including), that

give to it measurement between -10 to 100°C.

ST-100 SPECIFICATIO NS

APPLI CATIO NS

Measuring principle Stand for coaxial measuring systems

thermostated by Peltier effect.

Temperature With ambient air: 10 – 65°C +/- 0.2°C

With cryostat bath (not include):

-10 – 100°C +/- 0.2°C

Digital display Regulation set-up and

actual temerature of cell

Supply voltage 90-240 VAC 50/60 Hz

Other detail ST-100 coul be associated to all coaxial

geometries of RM 300

Dimensions (WxLxH) and weight Electronic box:

257 x 267 x 200 mm

Stand: 197 x 280 x 485 mm

15 kg

Name Reference Dimensions Volume Viscosity range

MK-DIN 145 112504  45 mm _ 3 - 900 000 mPa.s

MK-DIN 125 112503  25 mm _ 5 - 5 000 000 mPa.s

MK-DIN 114 112502  14 mm _ 15 - 30 000 000 mPa.s

MK-DIN 108 112501  8 mm _ 80 - 150 000 000 mPa.s

MB-DIN 145T

cup 112512  48.5 mm 100 ml _

MB-DIN 125T

cup 112511  27.5 mm 20 ml _

MB-DIN 114T

cup 112510  15 mm 5 ml _

MB-DIN 108T

cup 112509  8.5 mm 2 ml _

MK-MS0 112702  46.5 mm _

1 - 28 000 mPa.s

MS-0 cup 112701  50 mm 20 ml

MK-C 112525  13.6 mm _ 50 mPa.s - 50 000 000 mPa.s

MK-C2 112550  17.6 mm _ 20 mPa.s - 20 000 000 mPa.s

MK-C4 112552  19 mm _ 2 - 900 000 mPa.s

MB-C cup 112524  20 mm 20 ml

APPLICATIONS：

Food industry Chemical industry Teaching
Cosmetics/Pharmaceuticals Building industry
Paint/Ink Cars industry
