電源電壓(v/Hz)voltage

AC220/50

真空泵電機功率(W)Motor Power

1000

熱封功率(W)Sealing Power

1000

真空室zui低絕對壓強(Kpa)Ultimate Vacuum Pressure

1

每室熱封條數(pcs)No.of Sealing Bars for Each Chamber

2

真空室內尺寸(LxWxH)(mm)Chamber Dimension

630*630*100

熱封條長度Sealing Length

400/500/600

熱封寬度Sealing Width

10

真空泵排氣量(m³/h)Vacuum Pump Rate

20

真空室材質Material for Vacuum Chamber

不銹鋼Stainless steel  201

外形尺寸（LxWxH)(mm)Dimension

760*750*980

凈重Net Weight

111

兩條封口之間的中心距離The center distance between two sealing bars

540
